600kV Energy Storage Cable UL 1284
- Model
- UL 1284
Item specifics
- Conductor
- Tinned copper stranded, or bare copper
- Insulation
- Lead free PVC, Passed RoHS
- Rated temperature
- 105°C
- Rated voltage
- 600V AC
- Flame test
- Horizontal flame UL VW-1 & CSA FT1
- According to
- UL758, UL1581
Review
Description
UL 1284 Energy Storage Cable Advantages
UL 1284 Energy Storage Cable
UL 1284 energy storage cables are crucial components in energy storage systems (ESS), serving to connect and transmit electrical power between different system elements, such as batteries, inverters, and the grid. Battery storage cables are designed to handle high currents and voltages, ensuring the efficient and safe transfer of electricity in systems like lithium-ion or flow batteries, which are commonly used for storing energy from renewable sources such as solar.
· Anti-moisture
· Acid resistant
· Oil resistant
· Easy stripping and cutting
Technical Data
|
Conductor:
|
Tinned copper stranded, or bare copper stranded or solid conductor
|
|
|
Insulation:
|
Lead free PVC, Passed RoHS |
|
|
Rated temperature:
|
105°C
|
|
|
Rated voltage:
|
600Vac
|
|
According to: | UL758, UL1581 | |
Flame test: | Horizontal flame
UL VW-1 & CSA FT1 | |
Product description
Cable Name |
Cross Section
(AWG) |
Insulation Nom Thickness
(mm) |
Cable O.D.
(mm) |
Conductor Resistant Max at 20°C (Ώ/km) |
UL 1284 | 8 | 2.03 | 8.30 | 2.35 |
7 | 2.03 | 8.80 | 1.87 | |
6 | 2.03 | 9.40 | 1.48 | |
5 | 2.03 | 10.0 | 1.17 | |
4 | 2.03 | 10.70 | 0.928 | |
3 | 2.03 | 11.50 | 0.744 | |
2 | 2.03 | 12.50 | 0.590 | |
1 | 2.03 | 13.50 | 0.467 | |
1/0 | 2.03 | 14.60 | 0.370 | |
2/0 | 2.03 | 16.00 | 0.297 | |
3/0 | 2.03 | 17.50 | 0.236 | |
4/0 | 2.03 | 19.10 | 0.187 |
