35kV Solar Power Cable Medium Voltage MV-90, MV-105
- Model
- MV-90, MV-105
Item specifics
- Rated voltage
- 35kV
- Maximum Conductor Temperature
- (MV-90)90°C, (MV-105)105°C
- Conductor
- Aluminium alloy
- Insulation
- TR-XLPE
- Conductor and Insulating shield
- Semi-conductive XLPO
- Concentric Neutral Conductor
- Bare copper
- Jacket
- (MV-90)LLDPE, (MV-105)XLDPE
- Reference Standard
- ICEA S-94-649, UL 1072
Review
Description
MV-90, MV-105 Solar Cable Advantages
35kV Solar Power Cable Medium Voltage MV-90, MV-105
The MV-90 and MV-105 medium voltage solar cables are designed specifically for medium voltage transmission needs up to 35kV, making them the ideal solution for connecting generation units to the medium voltage distribution network in photovoltaic systems. These cables not only feature smaller conductor cross-sections, which reduce material and installation costs, but also support longer distance transmission, lowering the overall project cost. Additionally, they are capable of withstanding complex and variable environmental conditions such as wet or dry locations, direct burial, pipe installation, and exposure to sunlight. With their exceptional medium voltage capacity, they provide reliable and efficient power transmission for both distributed photovoltaic systems and large-scale ground-mounted solar power plants.
· Rated for direct burial
· Duried in conduit
· Low smoke halogen free
· Higher insulation resistance
· High Voltage
MV-90, MV-105 Solar Cable Technical Data
|
Maximum Conductor Temperature
|
MV-90: 90°C
MV-105: 105°C |
|
|
Rated voltage
|
35kV
|
|
Reference Standard | ICEA S-94-649
UL 1072 | |
MV-90, MV-105 Solar Cable Product description
Cable Name |
Cross Section
(AWG) | Insulation Thickness
(mm) |
Outer Layer Thickness
(mm) |
Cable O.D.
(mm) | Conductor Resistance Max
(Ώ/km,20°C) |
35kV Solar Cable Aluminum Conductor MV-90, MV-105 | 4/0 AWG | 10.67 | 2.03 | 45.02 | 0.274 |
500 MAM | 10.67 | 2.03 | 53.42 | 0.116 | |
750 MAM | 10.67 | 2.03 | 59.36 | 0.077 | |
1000 MAM | 10.67 | 2.03 | 61.39 | 0.0581 | |
1250 MAM | 10.67 | 2.03 | 65.38 | 0.0462 |
