600V Solar Cable Aluminum Conductor USE-2
600V Solar Cable Aluminum Conductor USE-2
600V Solar Cable Aluminum Conductor USE-2
600V Solar Cable Aluminum Conductor USE-2
Model
USE-2

Item specifics

Rated temperature
-40°C~90°C
Rated voltage
600V
Insulation
XLPE,Type USE-2
Conductor
Aluminum
Reference Standard
UL854, UL1893

Review

Description

USE-2 Solar Cable Advantages
solar cable
600V Solar Cable Aluminum Conductor USE-2
USE-2 conductors are stranded, compressed 1350-H16/H26 (3/4 Hard) aluminum insulated with cross-linked polyethylene. They are UL listed as Type USE-2. These cables with 600V voltage can operate continuously at a conductor temperature not in excess of 90°C for normal operation in wet and dry locations, 130°C for emergency overload, and 250°C for short circuit conditions.

· Can be buried directly
· Wearable tubes and slots
· Can be used in wet and dry environments

USE-2 Solar Cable Technical Data
Rated temperature
-40°C~90°C
Rated voltage
600V
Reference Standard
UL854, UL1893
aluminum solar cable
aluminum conductor cable
USE-2 Solar Cable Product description
Cable Name
Cross Section
(AWG)
Inner Layer Thickness
(mm)
Cable O.D.
(mm)
Conductor Resistance Max
(Ώ/km,25°C)
600V Solar Cable Aluminum Conductor USE-2
6
1.52
7.57
0.674
4
1.52
8.76
0.424
2
1.52
10.24
0.266
1
2.03
12.01
0.211
1/0
2.03
13.00
0.167
2/0
2.03
14.10
0.133
3/0
2.03
15.32
0.105
4/0
2.03
16.71
0.084
250
2.41
18.59
0.071
300
2.41
19.91
0.059
350
2.41
21.11
0.050
500
2.41
24.28
0.035
600
2.79
27.58
0.029
700
2.79
29.44
0.024
